It has extremely low headroom dimensions and can be suitable for a variety of applications.

Load range: 0.5T-20T

Product Features

• This series of hoists with a rated load of less than 3000 kg all adopt a single chain structure, with a lower clearance size, especially suitable for Applications where space is limited.

• The trolley is very easy to install and adjust, and can be precisely adjusted according to the width of the steel beam.

• The trolley with a rated load of less than 5 tons can be set to two basic standard specifications. The type A trolley is suitable for I-beams with a maximum width of 180 mm, and can be easily converted to type B to suit I-beams with a maximum width of 300 mm.

• The wheel design of the trolley ensures a relatively large track contact surface, and the lubricated sealed ball bearings ensure the wheel Works well.

• The trolley is equipped with anti-tilt and anti-fall devices as standard.

• You can also purchase an IT-type trolley separately for use with the MSS360 chain hoist.

Product Options

• This corrosion protection option

• Explosion proof options(ATEX)

• Overload protector

• Chain bag

• Car anti-collision block

• Models with rated load up to 5 tons and lifting height not exceeding 3
