Ultra-low headroom MUTIAN MSAD The integrated push or pull trolley combination is MUTIAN-Gourd Series MSAJ An upgraded version of this model that can be used with lower clearance requirements.

Product Features

• The newly developed chain guide can pull the hoist chain from the side of the hoist body, almost level with the steel beam Use the same integrated trolley as MSAJ.

• Hoists in this series of products with a rated load below 2000 kg all adopt a single chain structure.

• The trolley is very easy to install and adjust, and can be precisely adjusted according to the width of the steel beam.

• The trolley can be set to two basic standard specifications. The A-type trolley is suitable for I-beams with a maximum width of 180 mm. It can be easily converted to B-type to fit  I-beams with a maximum width of 300 mm.

• The wheel design of the trolley ensures maximum track contact surface, while the lubricated sealed ball bearings ensure the steel quality.Good running of the wheels.

• The trolley can be optionally equipped with anti-fall and anti-tilt devices.

Product options in various forms

   A. low-headroom hoists designed for low spaces and special suspended lifting trolleys are suitable for all types of lifting and transportation.

   B. Optional chain strap (fabric bag or metal box)

   C. Explosion-proof option (ATEX)

   D. Anti-corrosion options

   E. Overload protection device

   F. the trolley fixing device prevents Accidental sliding (especially suitable for use on boats)
