The MSAJ hoist car assembly has a very low clearance size and can be used in a variety of applications.
· product features
The hoist with rated load of less than 2000kg adopts single chain structure and lower headroom size, especially suitable for applications with limited space.
The car is easy to install and adjust, and can be precisely adjusted according to the width of the steel beam.
The car with A rated load of less than 5 tons can be set as two basic standard specifications. The type A car is suitable for the i-beam with A maximum width of 180 mm, and it can be easily converted into type B with A maximum width of 300 mm.
The car wheel is designed to ensure the maximum track contact surface, and the use of lubricated compact ball bearings to ensure the good operation of the wheels.
The car is equipped with standard tilting and anti-falling device.
You can also purchase the integrated trolley separately for the MUTIAN MSA hand-pull hoist.
· multiple forms of product options
A. low headroom hoist designed for low space and special suspension crane are suitable for all kinds of lifting loads for transportation.
B. Optional chain strap (fabric bag or metal box)
C. Explosion protection options (ATEX)
D. Anti-corrosion options
E. overload protection device
D. fixed device for trolley to prevent accidental sliding (especially suitable for use on board)
