The product lifting range is 0.25T~0.5T

Product Features

• Compact and light weight：

Our best and most rugged design, all-steel manual chain hoist; The load-bearing mechanism increases mechanical efficiency.

• Special hook

The drop forged top hook and hook are specially designed with slow bending to avoid overloading.

• New design

The open frame design allows for self-cleaning, quick inspection of the cargo sheaves and simple hoist maintenance.

• Collision Avoidance

The convex rib technology is impact-resistant and effectively protects the internal transmission mechanism.

• Safety brake

Brake discs that do not contain asbestos that is effectively carcinogenic; The lifting chain sprocket is made of alloy steel and is precisely machined and heat treated.

• Double pawl

according to CE Standard, spring-loaded double pawls provide more reliable operation of the brake mechanism. Risk-free protection against overload (optional) The overload limiter protects the hoist structure from damage.

• Product options in various forms

A. Low headroom hoists and special suspended lifting trolleys designed for low spaces are suitable for all kinds of lifting and transportation.

B. Optional chain strap (fabric bag or metal box)

C. Explosion proof options(ATEX)

D. Corrosion protection options

E. Trolley fixing device to prevent accidental sliding (especially suitable for wearing)

F. Overload protection device
