New upgraded design • High protection level, long service life, low clearance height, more space saving.

Working level • High-level M5 working grade, built-in air cooling, suitable for high-frequency and high-lift working conditions.

Protection level • IP55Protection level, dust-proof body, suitable for Working in harsh environment.

Heat dissipation device • A heat sink is set on the motor frame, through the built-in The cooling fan cools the entire body; not only does it maintain cooling performance, it also keeps the motor unit itself silent.

Power-off brake • Achieve instant braking when the power is cut off.

Limit switch • There are limit switches when lifting heavy objects up and down, which can make the motor Automatic stop to prevent the chain from overrunning, ensuring safety.

Reverse phase protection device • For special electrical devices, when the power wiring is wrong The control circuit cannot work.

Braking device • This device can achieve instant braking when the power is cut off.

Thickened shell • Thickened upgraded aluminum alloy shell, light and sturdy.

Wired control handle • Ergonomic design, press the emergency stop button That is, the motor circuit is cut off.

Chain • Adopt national standardG80Super strong heat-treated manganese steel chain, low wear,Corrosion resistant.
