Double cam claw design, range 800kg - 9000kg, equipped with unique dual brake Mechanism, providing overload protection device, suitable for simultaneous use of inverted and horizontal two-position telescopic and tensioning new double pawl ratchet brake design, can realize fine adjustment function during the lifting and lowering of the handle.

Light load tested and certified at 2% of rated.

The safe load capacity is tested at 1.5 times the rated load.

Operating temperature range: -40℃ to 50℃.

Lightweight, compact, rugged construction with handle, gearbox and brake cover stamped Made entirely of steel, it is highly resistant to impact damage. Using only the highest quality materials and accurate processing throughout ensures that MUTIAN is the ideal hoist for long-term use with less maintenance and upkeep costs.

Hook: Forged and heat treated alloy hooks are equipped with heavy duty lock kits to fully engage the hook Product larger loads secure nose.

Forgings: Embedded forgings provide integral protection to all our bottom hook load chain feet.bolt.
