Comply with current standards MUTIAN Equipment that combines aesthetics, compact design and high performance

※ Standard load limiters

※ The lifting nut and reduction gear set are specially manufactured to achieve more efficient and smooth operation during lifting operations.

※ Standard lifting height: 3 meters (other height specifications can be provided upon request) The Operation chain length is 50 cm shorter than the lifting chain.

※ Made of 80 grade high strength alloy steel, galvanized for rust prevention,

※ EN818 standard, safety factor of 4:1, high strength lifting chain.

※ Electro galvanized handling chain,

※ MUTIAN The compact design achieves a lighter body and smaller size.The hoist is ideal for construction, installation and maintenance work.

※ Steel covers provide solid protection for mechanical parts such as lifting nuts, gears, etc.

※ Alloy steel upper and lower rigging with safety lock design (compliant with ISO standard).

※ WESTON Type lifting brake.High-strength powder coating in RAL7021 color and 70 micron thickness.

※ Attached CE Certificate delivery including hook and chain certification documents.

Options:Current extensive range of options on hoists:

※ INOKS Maneuvering and lifting chains with VHR.

※ Chain bucket.
